Unwinding part：
Unwinding device is independent ,it uses steel framed structure
Install one set of removable loading device . move guide rail use ABBA import element.
Chuck is 3 inches, controlled by hydraulic locking device
Loading device up and down controlled by hydraulic oil cylinder at left and right.
Unwind brake is 10kg brake , tension is controlled by manual .
One set of heavy duty LPC device .
Rewinding part：
Machine with round knife device
Round knife shaft up and down is controlled by manual.
One rubber bent roller with manual adjustable direction
Rewinding shaft uses a air shaft with a 3 inches paper core
Rewinding tension is manual tension
Unloading uses removable way , loading by hydraulic lift .
1 set of air tube and a waste blower
Rewind by 10kg clutch.
Electric part：
Main inverter YASKAW 7.5KW
Main motor 7.5kw
Rewind tension is controlled by manual.
The functions with automatic reduce the speed and automatic stop.
The functions with indication at the end of material.
The functions with set reduce the speed advance and stop.
The functions with fault indication.
LPC limited stop automatically.
Technical Parameters：
Machine Model | FJ-800 |
Max. rewinding diameter | 1300mm |
Max.unwinding diameter | 1000mm |
Mechanical speed | 50m/min |
Slitting Rewinding Width | 100-500 mm |
Rewind paper core | 76mm |
Unwind Paper core diameter | 76mm |
Weight | ～3800㎏ |
Voltage | AC380V+N 50HZ |
Total power | ～11KW |
EPC precision | +1mm |
